Pilbara Mining Region
Australia Overview

Banded iron formations in the Hamersley Basin. About 2.4 billion years old. Cyanobacteria oxygenated the atmosphere, dissolved ocean iron precipitated out in alternating layers with silica. The unaltered rock grades 25% to 35% Fe, which is not worth shipping. The commercial deposits exist because groundwater spent geological time dissolving silica out of the BIF along fault systems and ancient water tables, leaving iron oxides above 60% Fe. The enrichment geometry follows paleodrainage that eroded away in the Tertiary, so the grade boundaries underground bear no relationship to the surface topography. Grade control drilling on 25-metre spacing can still get the boundary wrong.

This is the part of Pilbara mining where the money is actually made or lost at the margin, and the part that tends to get compressed into a paragraph when it deserves much more room.

Rio Tinto's Pilbara Blend Fines targets about 61.6% Fe, 3.3% SiO₂, 2.2% Al₂O₃, 0.065% P. Sixteen mines feed this product, each with different and internally shifting geochemistry as pit faces advance through geological zones. The operations centre in Perth treats the network as a single system, deciding which ore goes on which train to which stockpile to load which ship. An off-spec cargo at a Chinese port triggers penalties that can exceed a million dollars on 170,000 tonnes. Hundreds of cargoes a year.

Alumina in the blast furnace feed increases slag viscosity. More coke, more flux needed to compensate. At coke prices of $300 to $500 a tonne, the difference between 2.0% and 2.5% alumina in the feed is large enough that Japanese steelmakers running big optimised furnaces at Kimitsu or Fukuyama have paid above-benchmark for low-alumina Pilbara ore for decades. The coke saving at their end exceeds the premium at the mine end.

Phosphorus below about 0.07% in the ore is manageable through normal practice. Above that, dephosphorisation requires extended BOF blow times and sometimes secondary refining. The cost ramp is nonlinear. Deposits with phosphorus consistently below 0.05% carry an advantage that lives inside confidential long-term contracts and does not appear in the Platts 62% Fe index.

The lump-to-fines ratio sits alongside blending as the other place where geology turns directly into revenue. Hard hematite breaks coarse, softer goethite-rich ore crumbles. Lump (above 6.3mm) goes into blast furnaces without sintering and carries a premium of $5 to $15 per tonne. The ratio is mineralogically fixed. BHP built South Flank for roughly $3.6 billion primarily to secure a better lump ratio as Yandi wound down.

Moisture. Fines sell dry-weight but ship wet. Every tonne of water in the hold displaces payable ore. The transportable moisture limit caps cargo wetness against liquefaction risk. The commercial band between revenue loss from excess water and safety risk from insufficient moisture is narrow.

Cape-size vessels transit the entrance channel around high tide only, two to three hours per cycle. Miss the window, twelve hours at anchor. The entire BHP and Fortescue supply chain synchronises to this tidal constraint. BHP has studied an outer harbour for over a decade. Tens of billions in estimated capital. Not built.

Rio Tinto blasted two rock shelters at Juukan Gorge in May 2020 for the Brockman 4 expansion. Forty-six thousand years of continuous Aboriginal occupation documented. A 4,000-year-old length of plaited human hair among the artefacts.

Section 18 consent under the Aboriginal Heritage Act 1972, obtained in 2013, before the most significant archaeological findings. The Act allowed no mechanism to revoke consent.

The heritage team within Rio Tinto knew the significance. They wrote reports. They flagged it. They could not stop a blast that had been engineered into the mine plan and scheduled months in advance. Heritage was advisory. The blast schedule was operational. Advisory does not override operational.

Three executives resigned. The 2021 and 2023 replacement legislation introduced mandatory permits, tiered assessment, statutory authority for knowledge holders. Six to eighteen additional months on Pilbara project timelines.

The Pilbara is the country of the Banjima, Yinhawangka, Nyiyaparli, Kariyarra, Puutu Kunti Kurrama, Pinikura, Eastern Guruma, and other nations. Fifty thousand years of occupation at minimum.

What has not been tested yet under the new legislation is a case where a permit denial blocks access to a large, high-quality ore deposit that a major producer has already incorporated into its long-range mine plan and communicated to shareholders in a reserves statement. When that collision happens, and given the density of heritage sites across the Hamersley Range it will happen, the new framework will face its defining moment. The outcome will tell the industry whether heritage authority under the 2021 Act is substantive or procedural.

The fight for berth access at Port Hedland in the early 2000s was a competition law dispute about essential facility doctrine. BHP contested. National Competition Council and state government got involved. Fortescue secured Anderson Point.

Fortescue's strategic vulnerability has always been product quality. Early shipments traded at steep discounts. The company has spent fifteen years and very large sums trying to close the gap. Iron Bridge's $3.9 billion magnetite concentrate at 67% Fe is the latest and most expensive attempt. Operating costs came in above initial guidance, which is the normal trajectory for magnetite projects through the feasibility-to-operation transition.

Fortescue Energy (formerly Fortescue Future Industries) and Andrew Forrest's personal green hydrogen advocacy deserve frank assessment. The ratio of announcements to operating assets is high. The 2030 zero terrestrial emissions target is the most ambitious in the sector. Capital is being allocated to pre-feasibility hydrogen ventures across multiple continents while the core iron ore business still depends on hematite fines trading at a quality discount. Institutional shareholders who bought a mining company and find themselves exposed to speculative energy development have applied periodic pressure. The share price tracks the iron ore price and does not move on energy division announcements. The market has made its assessment. Whether the market is wrong about the energy business is a different question, and Forrest's track record of building things that the consensus said could not be built is long enough that dismissing the hydrogen ambition outright would be unwise. The Pilbara's solar resource, above 2,500 kWh/m²/year, is among the best on Earth. The gap between that physical resource and bankable green hydrogen at industrial scale is still mostly a gap in electrolyser cost. How fast that gap closes determines whether Fortescue Energy is visionary or a misallocation of mining cash flow. Within the industry, opinion splits roughly by age. People who built careers in iron ore tend toward scepticism. People under forty tend to think the energy transition will arrive faster than the miners are planning for. Both groups are extrapolating from their own experience.

Simandou in Guinea is the development most likely to alter the Pilbara's competitive position, and it deserves more space than it usually gets in Pilbara overviews because the Pilbara's pricing power depends on the absence of a high-quality alternative at scale.

Simandou's reserves are large and the ore is high-grade. The Guinea-to-China shipping distance is shorter than Brazil-to-China. At full production, perhaps 100 to 150 million tonnes a year, it would be the largest new source of seaborne iron ore supply in decades. Rio Tinto is a partner in the joint venture, which gives it a hedge that BHP and Fortescue do not have.

The 670km rail line and deepwater port have not been built. The timeline has slipped repeatedly. Guinea's military government imposed new fiscal terms in 2022. Guinea's post-independence political history does not inspire confidence in long-term infrastructure commitments. Multiple previous attempts to develop Simandou have stalled. The BSGR saga, the renegotiated joint venture structures, the coups, the changing fiscal regimes. Every few years a new consortium announces a firm timeline, and every few years the timeline moves.

3 June 2008, a pipeline rupture and explosion at the Varanus Island gas processing facility near Dampier. Roughly 30% of Western Australia's gas supply offline for weeks. Pilbara mines curtailed production. The region generates its own power, disconnected from the state grid, from gas piped in from Carnarvon Basin offshore fields. Every renewable energy announcement from the three producers since then carries this context alongside the emissions context.

Autonomous haul trucks, drills, driverless trains. The technology works. Mine-site headcount drops. Supervisory work migrates to Perth. Newman, Tom Price, Paraburdoo were built for mine workers. The economic rationale for these towns weakens with each autonomous deployment. The services, schools, Aboriginal community infrastructure embedded in them do not scale down smoothly. Nobody in government is describing this trajectory openly.

Royalties at about 7.5% of mine-head value. Over $10 billion a year when prices exceed $100 per tonne. The price has been below $40 and above $230 within six years. Budget forecasting involves wide error bars.

Average mined grades across the region are declining as the richest supergene deposits deplete. Replacement mines cost more. Channel iron deposits and beneficiated BIF will grow as a share of output. The cost curve lifts. Magnetite may grow in importance if hydrogen-based direct reduction steelmaking expands, since DR plants need feedstock above 67% Fe.

China has tariffed Australian barley, wine, lobster, timber, coal. Not iron ore. Carajás is half the tonnage and 10,000 nautical miles further from Chinese ports.
